X-600M™ | Web Enabled I/O Controller
Remotely control and monitor up to 64 expansion modules and 128 ControlByWeb products via web browser for a tailored solution to your unique applications!
Expandable & Full-Featured
Expansion Modules
Add up to 64 expansion modules and/or remote I/O devices for remote monitoring and control for up to 1,024 I/O.
Custom Logic
Create custom logic via the X-600M interface or advanced logic with Lua scripts.
Control & Monitoring
Control and/or monitor over any TCP/IP network including private networks, IP-based industrial control networks, and the Internet.
Unlimited Possibilities! Control up to 1,024 I/O
Overview
The X-600 Modular Series is the ultimate drop-in solution for monitoring and control. Start with the X-600M™ master controller and add I/O by connecting expansion modules for a solution that is tailored to your specific application. Expansion modules include relays, digital inputs, analog inputs, thermocouples and more. This series has many powerful features and will be an ideal solution for many applications.
The X-600M is a web-enabled I/O controller that performs control, logic, and monitoring functions similar to that of a Programmable Logic Controller (PLC). However, unlike a PLC, the X-600M is designed for web based applications from the ground up. The X-600M can be setup, controlled, and monitored using its built-in web server and a standard web browser. The setup web pages are intuitive and easy to use and do not require special programming skills. No add-on software is required.
The X-600M functions as a powerful master controller for other ControlByWeb™ modules. Its ribbon-cable expansion bus connector allows for up to 64 expansion modules to be connected directly to the X-600M*. It can also control any of our other stand-alone ControlByWeb devices over an Ethernet network - Up to 128 devices!
Many powerful features are included in this new series; such as customizable Email notifications, scheduling, logging and graphing of logged data, custom Lua scripts, and much more.
Expansion modules for the X-600M are available for adding relays, digital inputs, thermocouples, and more.
*Power injector may be required for configurations larger than 16 modules.
Expansion Modules
Add I/O expansion modules (below) to the X-600M for a solution that is tailored to your application.
The possibilities are endless!
Features
- Built with:
- Industrial grade components
- High-reliability SLC flash
- Transient protection
- Watchdog timers
- Voltage supervisor circuitry, etc.
- Powerful built-in web server
- Easily configurable web pages
- Logging & automatic graphing of log files
- Built-In Ethernet switch with two Ethernet connections
- Expansion bus - Direct connection with up to 64 modules*
- Communicates with all ControlByWeb modules such as, WebRelay, WebRelay-Quad, Analog Module, X-300, etc.
- Up to 1,024 I/O points
- Supports USB WiFi adapters & USB flash drives
- Built-in 1-wire bus for temp/humidity sensors
- Send custom email alerts using encrypted email servers (Gmail, Yahoo, etc.)
- Create logic scripts or full programs using Lua
- Advanced, full-calendar scheduling
- Protocols supported: HTTP, HTTPS, SSL, SMTP, Modbus/TCP, Remote Services™ server and client, & more.
- Email alerts based on user-defined conditions
- Static or DHCP IP address configuration
- XML, Modbus/TCP, & SNMP interface options
- Field updatable
- Removable 5-pin terminal connector
- Rugged DIN-Rail/wall-mountable enclosure
Examples
Automatic Reboot
Automatically reboot a device, such as a server, computer, router, etc., by sending ping requests. If a preset number of ping requests fail, the X-600M will then attempt to restore the device to normal operation by rebooting. View Instructions ❯
Shift Bell Controller
Set multiple schedules to control numerous shift bells and control which schedule is active using a web browser. Includes example of how to configure holiday and regular schedules. View Instructions ❯
Temperature Monitoring
Send customizable, user-defined email alarms based on temperatures recorded from 1-Wire temperature sensors connected directly to the X-600M. Temperature alarms are defined by the user. View Instructions ❯
Thermostat Controller
How to use the X-600M as a full featured single-stage thermostat with 7-Day scheduling for efficient operation of HVAC systems. It can read temperatures from a sensor connected directly to the X-600M, or it can read remote temperatures across an IP network. View Instructions ❯
Videos
X-600M Wiring and Installation
This X-600M video shows how to mount the X-600M to a DIN-Rail, how to wire it to a power supply, connect it to expansion modules, and connect it to your network. View ❯
Establishing Communications: Automatic Method
This video shows how to establish communications with the X-600M using the automatic method using DHCP and NetBIOS, and how to log into the setup pages. View ❯
Establishing Communications: Manual Method
This video shows how to establish communications with the X-600M using the manual method by temporarily assigning an IP address to a computer so that they are on the same network. View ❯
X-600M Basic Setup
This video explains the basics of configuring the X-600M along with the overall setup strategy. View ❯
Communicating with ControlByWeb Stand-Alone Products
This video explains the basics of configuring the X-600M along with the overall setup strategy. View ❯
X-600M Part Numbers (Differences highlighted in green)
| PART NUMBER | OUTPUTS | INPUTS | POWER SUPPLY |
|---|---|---|---|
| X-600M-I | See Expansion Modules | Temp: 32 (-67°F to 257°F (-55°C to +125°C)) | 9-28VDC |
More Information:
SpecificationsExpansion Modules
X-11s™ | Dual, High-Current Relay Expansion Module
Part number(s): X-11s (Requires an X-400 or X-600M controller)
HARDWARE FEATURES
- 2 large SPDT (Form C) relays (277 VAC (general purpose) 110VDC (NO contact, resistive) 30 VDC (NC contact, resistive) and 20A)
- Removable locking connector supports 24AWG to 10AWG
- Two relay LEDs
- Powered through expansion bus
X-12s™ | Eight-Relay Expansion Module
Part number(s): X-12s (Requires an X-400 or X-600M controller)
HARDWARE FEATURES
- 8 SPST (Form A) relays with shared common connection (2 commons)
- Removable terminal connector
- Eight relay LEDs
- Powered through expansion bus
X-13s™ | Thermocouple Expansion Module
Part number(s): X-13s-K (Requires an X-400 or X-600M controller)
HARDWARE FEATURES
- Supports one or two type K thermocouples
- Fault LED for each thermocouple
- Powered through expansion bus
X-15s™ | Eight Digital Input Expansion Module
Part number(s): X-15s (Requires an X-400 or X-600M controller)
HARDWARE FEATURES
- 8, Optically-Isolated inputs with shared common for each input
- Indicator LED for each input
- Automatic de-bounce
- Interrupt output to Master (X-600M) for fast response
- Built-in timers, counters, for each input
- Removable terminal connector
- Powered through expansion bus
X-16s™ | Eight Analog Input Expansion Module
Part number(s): X-16s (Requires an X-400 or X-600M controller)
HARDWARE FEATURES
- 8, 0-5V precision analog inputs
- 24-bit A/D converter
- Single or differential input measurements
- 5.0V reference output
- Removable terminal connector
- Powered through expansion bus
X-17s™ | 4 Relay, 4 Input Expansion Module
Part number(s): X-17s (Requires an X-400 or X-600M controller)
HARDWARE FEATURES
- 4 SPST (Form A) relays
- 4 Optically-Isolated digital inputs (common negative)
- Removable terminal connector
- Powered through expansion bus
X-18s™ | 10 High-Current Relay Expansion Module
Part number(s): X-18s (Requires an X-400 or X-600M controller)
HARDWARE FEATURES
- 10 Large SPDT (Form C) relays (15A, 277VAC, 30VDC)
- 1/4 inch tab connectors
- 11 LEDs for relays and power
- Powered externally
X-19s™ | 16 Relay, 16 Digital and 4 Analog Input Expansion Module
Part number(s): X-19s (Requires an X-400 or X-600M controller)
HARDWARE FEATURES
- 16 SPST relays
- 16 Optically-Isolated digital inputs
- 4 Single-ended channels analog inputs
- 33 LEDs for relays, digital inputs, and power
- Powered externally
X-20s™ | 6 Relay, 6 Digital Input Expansion Module
Part number(s): X-20s (Requires an X-400 or X-600M controller)
HARDWARE FEATURES
- 6 SPDT (Form C) relays
- 6 Optically-Isolated digital inputs
- 13 LEDs for relays, digital inputs, and power
- Powered externally
X-21s™ | Four Relay Form C / SPDT Expansion Module
Part number(s): X-21s (Requires an X-400 or X-600M controller)
HARDWARE FEATURES
- 4 Form C / SPDT (Form C) relays
- Removable terminal connector
- LED Indicators for relays and power
- Powered through expansion bus
X-22s™ | Eight Analog Input Expansion Module
Part number(s): X-22s (Requires an X-400 or X-600M controller)
HARDWARE FEATURES
- 8 precision analog inputs
- Configurable voltage ranges: ±1V to ±10V
- Connect 4-20mA sensors. No external resistors required.
- High input impedance facilitates external resistors for voltage scaling, if required.
- Powered through expansion bus
Where to Buy
Click "Buy Online" to view part numbers and pricing. X-600M is available in the USA and internationally, and can be purchased either from us or an Authorized Distributor.
